Description
The GE electric 1/2 hp motor is a general purpose motor designed for industrial automation and motion control applications. With a service factor of 1.25 and rated load of 1/2 hp, it is suitable for various business and industrial uses. This motor operates on AC current type with a single phase AC phase and a nominal rated input voltage of 115 V. The NEMA frame suffix 48Y indicates a specific frame size and design for this electric motor.This product has been unopened and has been sitting on shelf as new old stock. Box tag shows manufacture date of 1/10/1996. We have sold a few of these motors and have used a few, too. No problems have been encountered with them so far.
Item is only as described on tag.
Item sells new elsewhere usually in $250 price range. Item may also be listed on eBay and may sell at either site.
B208, 1/2 Hp, 1725 Rpm, 48Y FR, 115 Vac, Dripproof, Resilient Base, 48S17D2109 General Specifications Part Description : Self Cooled Output HP : 0.50 Hp Frequency : 60 Hz Voltage : 115 V Current : 7.2 A Speed : 1725 rpm Service Factor : 1.25 Phase : 1 Efficiency : 66 % Duty : Continuous Insulation Class : B Design Code : NO DESIGN CODE KVA Code : M Frame : 48Z Enclosure : Drip Proof Overload Protector : Automatic Ambient Temperature : 40 °C Resilient Base Weight : 22.00 LB
| Enclosure | DP |
|---|---|
| Frame | 48Y |
| Horsepower | 1/2 |
| Mounting | Resilient Base |
| Phase | 1 |
| RPM | 1725 |
| Voltage | 115 |
